WS BSH-630 Horizontal Machining Center

Basic Info

Model No.: WS BSH-630 Horizontal Machining Center

Brand: GLAB

Worktable Size(mm): 500*600

Worktable Indexing: 1° × 360 (Optional: 0.001°)

Max Worktable Load(kg): 800

Worktable Surface Type (T-slots): 5-18-100

Max Workpiece Swing Diameter(mm): 1200

X-axis Travel (Worktable Left-Right): 800mm

Y-axis Travel (Spindle Box Up-Down): 600mm

Z-axis Travel (Column Front-Back): 785mm

Spindle Taper Type: BT40

Max Spindle Speed(rpm): 8000

XY Axes: Roller 45–45

Z Axis: Roller type

XY Axes / Z Axis (Diameter × Lead): 40 × 12 mm

Rapid Feedrate (X / Y / Z Axes): 30 / 30 / 30 m/min

Positioning Accuracy (X, Y, Z Axes): ±0.01 mm (Full Stroke)

Repeatability (X, Y, Z Axes): ±0.006 mm (Full Stroke)

B-axis Indexing Accuracy: 10″

B-axis Repeatability: 6″

Spindle Motor Power(kW): 95.5

Max Spindle Output Torque (FANUC System): 95.5Nm

Three-axis & B-axis Motor Power(kW): 3/3/3/1.8

Power Requirement(kva): 40

Overall Dimensions (Approx. L × W × H): 4000*3500*2800mm

Additional Info

Transportation: Ocean

Product Description

The High-Precision WS 630 Horizontal Machining Center is designed to deliver unmatched performance and accuracy in industrial manufacturing environments. This machine combines advanced engineering with robust construction, making it an ideal choice for demanding production needs. Whether you're working on aerospace components, automotive parts, or complex machinery, the WS 630 ensures precision and efficiency.

This Horizontal machining center is equipped with a range of cutting-edge features that enhance its operational capabilities. The machine boasts a rigid base design, ensuring stability during high-speed operations. Its high-precision spindle delivers superior torque and speed, while the advanced CNC control system allows for intricate programming and real-time monitoring. The WS 630 also features multi-axis capability, allowing for versatile workpiece handling and reducing setup time. Additionally, its user-friendly interface simplifies operation for both novice and experienced technicians.
